Titanium sheet/plate
Titanium sheet is a flat, thin metal made from the element titanium. They are widely used in a variety of industries due to their excellent strength-to-weight ratio, corrosion resistance, and biocompatibility.
Titanium sheets and sheets can be formed into various shapes and sizes to suit specific applications, including aerospace components, medical implants, marine equipment and chemical processing vessels.
To achieve different mechanical properties and surface finishes, they can be produced using a variety of processes including hot or cold rolling, annealing and pickling.
Email: [email protected]
WhatsApp: 0086-13788924073
The titanium sheet metal and titanium alloy plate and sheets in accordance with ASTM B265, ASME SB265 standards, and other regional standards.
With over 30 years of experience as a titanium sheet supplier in China, Shanghai Changjin Metal Product Co.,Ltd. has established itself as a trusted provider of titanium plates.
The company’s extensive knowledge in titanium supply has allowed them to witness the evolving titanium industry and stay ahead of the competition.
| Grades | Rolling | Thickness Range | Delivery States |
| 1, 2, 3, 4, 7 | Hot Rolled | 0.3 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 12 | Hot Rolled | 0.5 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 5, 6 | Hot Rolled | 0.8 < t <4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 1, 2, 3, 4, 7 | Hot Rolled | 0.3 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 12 | Hot Rolled | 0.5 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 5, 6 | Hot Rolled | 0.8 < t <4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M |
*Titanium plates are produced to: hot-rolled state (R), cold-rolled state (Y), annealed (M), quenched state (C).
Standard Medical Titanium Sheet and Plate sizes provided. Custom sizes and specs offered upon request.
| Grade | Size (mm) | State | Standard |
|---|---|---|---|
| Grade 2 and Grade 3 | 3 x 11 x (500~1000) | Bright | ASTM F67 |
| Grade 2 and Grade 3 | 3.5 x 12 x (500~1000) | Bright | ASTM F67 |
| Grade 2 and Grade 3 | 4 x 14 x (500~1000) | Bright | ASTM F67 |
| Grade 5 | THK 3~60 | Bright | ASTM F136 |
Standard Heat Exchanger Titanium Sheet and Plate sizes provided. Custom sizes and specs offered upon request.
| Grade | Thickness (mm) | Width (mm | Length (mm) | State | Standard |
|---|---|---|---|---|---|
| 1,7 | 0.5~0.8 | 200~500 | 500~2000 | M | ASTM B265 |
| 1,7 | 0.9~1.0 | 200~500 | 500~2000 | M | ASTM B265 |
| 1,7 | 0.5~0.8 | 500~800 | 500~2000 | M | ASTM B265 |
Standard Titanium Co. offers titanium foil in the following size ranges:
● 0.51-4.78 mm thickness
● 610-1220 mm width
● ≤6100 mm length
We also provide forging blanks and CNC precision machining services for our clients, covering industries such as energy, petrochemicals, steel, engineering machinery, plastics, prevention and control, hydraulics, healthcare, and food. Please feel free to send us drawings for inquiries.
Metalworking Services
CNC Machining
Sheet Metal Fabrication
Metal Welding
Metal Cutting
Metal Bending
Metal Punching
Metal Forging
Metal Sheet Rolling
Tube and Plate Drilling
Heavy Forging Press Capacity
Our heavy-duty forging presses support open-die forging and deformation of large-section forgings, including discs, shafts, blocks, and custom components. This capability enables us to meet the demanding forming requirements of heavy industrial applications.
Heat Treatment Capability
Heat treatment is a critical step in achieving the mechanical properties required for heavy-duty forgings. Our process capabilities meet the strength, toughness, and structural stability requirements for forged components used under demanding operating conditions.
Heavy Shaft Machining
We offer machining capabilities for large forged shafts and long cylindrical components, supporting both rough and finish machining. This capacity is suitable for stepped shafts, rotor shafts, rollers, and other heavy-duty forged shaft components.
Ring Forging Machining
Our machining facilities are capable of handling large ring-shaped forgings and circular parts that require precise turning, face machining, boring, and contour control. This capability is suitable for industrial ring blanks, heavy-duty circular parts, and machined ring forgings.
Cylindrical Forging Machining
We offer machining solutions for heavy-duty cylindrical, hollow, and tubular forgings. This capability supports the machining of sleeves, cylinders, and other thick-walled forged components used in pressure vessels, rotating systems, and general industrial applications.
Inspection & Testing
Quality control is integrated into our production process through the inspection and testing of forged and machined parts. Our capabilities help verify the dimensional accuracy, condition, and quality consistency of industrial forgings prior to delivery.
Packing & Delivery
Finished forgings are properly protected and packaged to minimize the risk of damage during storage and transportation. Our packaging methods ensure the safe domestic delivery and export shipment of machined and high-value forged components.
